Switch Pro 48 PoE Layer 3, PoE switch with (48) GbE RJ45 ports, including (40) 802.3at PoE+ ports and (8) 802.3bt PoE++ ports, and (4) 10G SFP+ ports. The Switch Pro 48 PoE (USW Pro 48 PoE) is a fully managed switch with (40) GbE, 802.3at PoE+ RJ45 ports, (8) GbE, 802.3bt PoE++ RJ45 ports, and (4) 10G SFP+ ports. The USW Pro 48 PoE combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 48 PoE is the ideal access layer switch for any UniFi system. It combines up to 600W of PoE power with SmartPower RPS (USP RPS) power redundancy. The switch can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app. Technical Specifications Mechanical Dimensions 442.4 x 399.6 x 43.7 mm (17.42 x 15.73 x 1.72") Weight With Brackets 6.25 kg (13.78 lb) 6.34 kg (13.98 lb) Interfaces Networking Management (48) 10/100/1000 RJ45 Ports (4) 1/10G SFP+ Ethernet Ports Ethernet In-Band Total Non-Blocking Throughput 88 Gbps Switching Capacity 176 Gbps Forwarding Rate 130.944 Mpps Power Method Universal Input USP RPS DC Input 100-240VAC/50-60 Hz 52VDC, 11.54A; 11.5VDC, 5.22A Power Supply AC/DC, Internal, 120W Supported Voltage Range 100 to 240VAC Max. Power Consumption (Excluding PoE Output) 60W LEDs System RJ45 Data Ports SFP+ Data Ports Status PoE; Speed/Link/Activity Link/Activity ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV Shock and Vibration ETSI300-019-1.4 Standard Operating Temperature -5 to 40° C (23 to 104° F) Operating Humidity 10 to 90% Noncondensing Certifications CE, FCC, IC PoE Total Available PoE 600W PoE Interfaces Ports 1-40 Ports 41-48 POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-) 60W PoE++ IEEE 802.3bt, (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-) Max. PoE Wattage per Port by PSE 802.3at 802.3bt 32W 64W Voltage Range 802.3af Mode 44-57V Voltage Range 802.3at Mode 50-57V
