Ubiquiti PowerBeam 2GHz AC 400mm
Popis a parametre
Ubiquiti PowerBeam 2GHz AC 400mm
https://dl.ubnt.com/datasheets/PowerBeam_ac/PowerBeam_PBE-2AC-400_DS.pdf Specifications PBE-2AC-400 Dimensions with Radome 420 x 420 x 289 mm (16.54 x 16.54 x 11.38") Weight (Mount Included) 1.795 kg (4.809 lbs) Power Supply 24V, 0.5A Gigabit PoE Adapter (Included) Max. Power Consumption 7.5W Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return) Supported Voltage Range 22 to 26VDC Gain 18 dBi Networking Interface (1) 10/100/1000 Ethernet Port Processor Specs MIPS 74Kc Memory 64 MB LEDs Power, Ethernet, (4) Signal Strength Channel Sizes PtP Mode PtMP Mode 10/20/40 MHz 10/20/40 MHz Enclosure Characteristics Antenna Feed Dish Reflector Outdoor UV Stabilized Plastic Powder-Coated SPCC Mounting Pole-Mounting Kit (Included) Wind Loading 342.5 N @ 200 km/h (77 lbf @ 125 mph) Wind Survivability 200 km/h (125 mph) ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV Operating Temperature -40 to 70° C (-40 to 158° F) Operating Humidity 5 to 95% Noncondensing RoHS Compliance Ye s Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5 Vibration Test IEC 68-2-6 Temperature Shock Test IEC 68-2-14 UV Test IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4 Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5 Certifications CE, FCC, IC
Ubiquiti PowerBeam 2GHz AC 400mm
