Technical Specifications
Mechanical
Dimensions O100 x 95 mm (O3.9 x 3.7")
Weight 550 g (1.2 lb)
Enclosure material Aluminum alloy, polycarbonate
Weatherproofing IP66
Resistance IK04
Cable jacket enclosure dimensions O20 x 70.6 mm (0.8 x 2.8")
Cable jacket enclosure materials Thermoplastic elastomer, polycarbonate, silicone rubber
Cable length 30 cm (1 ft)
Cable diameter 4.5 mm (0.2")
Cable jacket material Thermoplastic elastomer
Cable connector type RJ45

Optics
Sensor 1/1.8" 8MP
Lens Fixed focal length
View angle H: 109.9°, V: 56.7°, D: 134.1°
Night mode Built-in IR LED illumination and IR cut filter
IR distance 30 m (98 ft)

Video
Resolution 8MP 3864 x 2160 (16:9)
Max. frame rate 30 FPS
Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR

System
Processor Quad-core Arm® Cortex®-A53 based chip
Networking interface 10/100 MbE RJ45 port
Max. power consumption 12.5W
Power method PoE
Supported voltage range 37–57V DC
LED R/G/B/W
Button (1) Factory-reset
Mounting Ceiling, wall (Included)
Arm, pendant, junction box (Optional)
Ambient operating temperature -30 to 50° C (-22 to 122° F)
Ambient operating humidity 0 to 90% noncondensing
Certifications FCC, IC, CE

Audio
Microphone Yes (Can be disabled)

Software
Web application UniFi Protect
Mobile app UniFi Protect iOS™ and Android™
