Technical Specifications
Mechanical
Dimensions Without mount: O82 x 88.8 mm (O3.2 x 3.5")
With mount: O82 x 153 mm (O3.2 x 6")
Weight Without mount: 587 g (1.3 lb)
With mount: 737 g (1.6 lb)
Enclosure material Aluminum alloy, polycarbonate
Mount material Wall mount: aluminum alloy, polycarbonate
Pole mount: aluminum alloy
Weatherproofing IP66
Resistance IK04
Pole mount diameter 1.5–2" (38–50 mm)
Metal strap torque: 6 Nm

Optics
Sensor 1/1.8" 8MP
Lens Fixed focal length
View angle H: 109.9°, V: 56.7°, D: 134.1°
Night mode Built-in IR LED illumination and IR cut filter
IR distance 30 m (98 ft)
Video
Resolution 8MP 3864 x 2160 (16:9)
Max. frame rate 30 FPS
Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR

System
Processor Quad-core Arm® Cortex®-A53 based chip
Networking interface 10/100 MbE RJ45 port
Max. power consumption 9.9W
Power method PoE
Supported voltage range 37–57V DC
Button (1) Factory-reset
Mounting Wall, ceiling, pole mount (Included)
Junction box, angled base (Optional)
Ambient operating temperature -20 to 50° C (-4 to 122° F)
Ambient operating humidity 0 to 90% noncondensing
Certifications FCC, IC, CE

Audio
Microphone Yes (Can be disabled)

Software
Web application UniFi Protect
Mobile app UniFi Protect iOS™ and Android™
