Technical Specification System System Type: Server System Form Factor: Rack-Mountable Processor Supported CPUs: EPYC 7002 Series CPU Socket Standard: Socket SP3 CPU Maximum Quantity Supports: 1 Quantity of Mainboards Supported: 1 Memory Memory Type: DDR4 SDRAM Memory Form Factor: DIMM 288-pin Provides Error Checking Method: ECC Maximum Installable System Memory Storage Capacity: 4 TB Memory Slot Total Quantity: 16 Memory Features: Registered Load Reduced Eight DDR Channels Controller Integrated: Storage Controller: SATA (4) Storage Controller: PCIe/SATA (2 x M.2) Storage Controller: PCIe NVMe (12 x U.2) Remote Management Controller: Gigabit Ethernet (RJ-45) Video Output Video Controller Form Factor: Integrated Video Chipset: Aspeed AST2500 Networking Specifications Networking Form Factor: Integrated LAN Chipset: Broadcom BCM5720 LAN: Gigabit Ethernet Data Link Protocol Supports: Gigabit Ethernet/Fast Ethernet/Ethernet Bay Provided Number of 2.5-inch Hot-Swap Drive Bays: 16 Slot Provided PCI Express 4.0 x16: 2 Interface Provided USB 3.2 Gen 1: 2 (USB 3.2 (type A)) Serial: 1 (9-pin DB) VGA: 1 (15-pin D-sub) LAN: 1 (RJ-45) Management Port: 1 (RJ-45) Power Power Device Type: Power Supply - redundant Power Device Location: Internal Input Voltage: AC 100-240 V Power Device Installed Quantity: 2; Redundant (1+1) Power Device Maximum Quantity Supports: 2 Maximum Output Power: 850 W Miscellaneous External Colour: Black Mounting Capability: Rackmount Standard Rack Height: 1 U Environment Maximum Operating Ambient Temperature: 35 °C Maximum Operating Humidity: 90 % Minimum Operating Ambient Temperature: 10 °C Minimum Operating Humidity: 35 % Dimensions & Weight Device Height (mm): 43 mm Depth (mm): 680 mm Width (mm): 438.5 mm Nominal Weight: 10.5 kg
