Hardware Specs Software Specs CPU CPU Model Realtek RTD1619B CPU Quantity 1 CPU Architecture 64-bit CPU Frequency 4-core 1.7 GHz Hardware Encryption Engine Memory System Memory 2 GB DDR4 non-ECC Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Storage Drive Bays 2 Compatible Drive Type* (See all supported drives) 3.5" SATA HDD 2.5" SATA SSD Hot Swappable Drive* Notes "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. External Ports RJ-45 1GbE LAN Port* 1 USB 3.2 Gen 1 Port* 3 USB / SD Copy Notes This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. File System Internal Drives Btrfs EXT4 External Drives Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT Appearance Size (Height x Width x Depth) 165 mm x 108 mm x 232.7 mm Weight 1.28 kg Others System Fan 92 mm x 92 mm x 1 pcs Fan Speed Mode Full-Speed Mode Cool Mode Quiet Mode Brightness Adjustable Front LED Indicators Power Recovery Noise Level* 14.6 dB(A) Scheduled Power On / Off Wake on LAN / WAN Power Supply Unit / Adapter 60 W AC Input Power Voltage 100V to 240V AC Power Frequency 50/60 Hz, Single Phase Power Consumption 17.343 W (Access) 4.08 W (HDD Hibernation) British Thermal Unit 59.19 BTU/hr (Access) 13.92 BTU/hr (HDD Hibernation) Notes For more information on how power consumption is measured, refer to this article. Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75°C; Humidity: 58.2-61.8%. Temperature Operating Temperature 0°C to 40°C (32°F to 104°F) Storage Temperature -20°C to 60°C (-5°F to 140°F) Relative Humidity 5% to 95% RH Certification FCC CE BSMI VCCI RCM UKCA EAC CCC KC Warranty 2-year hardware warranty, extendable to 4 years with Extended Warranty Plus Notes Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions. The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) Environment RoHS Compliant Packaging Content Main Unit X 1 Accessory Pack X 1 AC Power Adapter X 1 AC Power Cord X 1 RJ-45 LAN Cable X 1 Quick Installation Guide X 1 Optional Accessories 3.5" SATA HDD: HAT5300 2.5" SATA SSD: SAT5210 VisualStation: VS360HD Surveillance Device License Pack
