Key Features 1. 560W High-efficiency Power Supply Gold Level Certified 2. 4x Hot-swap 2.5" SAS / SATA HDD trays 3. 1x Full-height, full-length AOC expansion slot 4. 3x 40x56mm 4-pin PWM fans and 2x 40x28mm 4-pin PWM fans for add-on card (optional) 5. Supports motherboard sizes of 12" x 13" & 12" x 10" (E-ATX, ATX, or Micro-ATX) Product SKUs CSE-111TQ-563CB SuperChassis 111TQ-563CB (Black) Form Factor 21.9" Depth 1U Rackmount Chassis - support for motherboard sizes of 12" x 13" and 13.68" x 13" Processor Support Supports dual, single Intel® / AMD processors Dimensions Width 16.8" (426mm) Height 1.7" (43mm) Depth 21.95" (558mm) Packaging 24" (W) x 8.3" (H) x 30" (L) Gross Weight 29 lbs (13.2kg) Available Color Black Expansion Slots • 1x Full-height, Full-length AOC expansion slot Drive Bays Hot-swap 4x Hot-swap 2.5" SAS / SATA HDD trays SAS or enterprise SATA HDD only recommended SAS / SATA Backplane 1U 2.5" SAS / SATA HDD backplane Peripheral Drives DVD-ROM Slim DVD-ROM Drive (optional) Front Panel Buttons Power On/Off button System Reset button LEDs Power status LED HDD activity LED 2x Network activity LEDs System Cooling Fans 3x 40x56mm 4-pin PWM fans 2x 40x28mm 4-pin PWM fans for add-on card (optional) Operating Environment (System) Operating Temperature Range 5°C ~ 35°C (41°F ~ 95°F) Non-Operating Temperature Range -40°C ~ 60°C (-40°F ~ 140°F) Operating Relative Humidity Range 8% ~ 90% (non-condensing) Non-Operating Relative Humidity Range 5% - 95% (non-condensing) Power Supply 560W AC power supply w/ PFC (24-pin) AC Voltage 100-240 V, 50-60 Hz, 7.5 Amp max +5V 18 Amp +5V standby 3 Amp +12V 46 Amp @ 100-180V; 49 Amp @ 180-240V -12V 0.5 Amp +3.3V 15 Amp Certification Gold Level Certified Gold Certified Regulatory (Power Supply) Power Supply Safety / EMC USA - UL listed, FCC Canada - CUL listed CCC Certification EN 60950/IEC 60950-Compliant Europe/CE Mark Germany - TUV Certified
