Panel Samsung QB32RBOD Diagonal Size 32 Type Edge LED BLU Resolution 1920*1080 (Full HD) Pixel Pitch(mm) 0.360(H) x0.360(V) Active Display Area(mm) 698.4(H) x 392.85(V) Brightness(Typ.) 400 nit Contrast Ratio 5000:1 Viewing Angle(H/V) 178/178 Response Time(G-to-G) 8ms(Typ.) Display Colors 16.7M(True Display)1.07B(Ditherd 10bit) Color Gamut 72% Operation Hour 24/7 Haze 2% Display Dynamic C/R MEGA H-Scanning Frequency 30 ~ 81kHZ V-Scanning Frequency 48 ~ 75HZ Maximum Pixel Frequency 594MHz Sound Speaker Type Built in Speaker(10W + 10W) Connectivity Input RGB Display Port 1.2 (1) Video HDMI 2.0 (2) HDCP HDCP2.2 Audio Stereo Mini Jack, HDMI/Audio(Common) USB USB 2.0 x 2 Output Audio Stereo mini Jack External Control RS232C(in/out) thru stereo jack, RJ45 External Sensor IR Power Type Internal Power Supply AC 100 - 240 V, 50/60 Hz Power Consumption Max[W/h] 72.0 Typical[W/h] 44.0 Rating[W/h] 65.0 BTU(Max) 245.7 Sleep mode 0.5 Mechanical Specification Dimension (mm) Set 725.1 x 419.6 x 34.6 Package 812 x 513 x 120 Weight (kg) Set 5.7 Package 8.0 VESA Mount (mm) 200 X 200 Stand Type Foot Stand (Optional) Bezel Width (mm) 8.8mm(U/L/R/B) Feature Key Features FHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0 Orientation Landscape / Portrait Remote Control N/A Special Features H/W : Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), IP5x Rating, Wi-Fi S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting) Internal Player Processor Cortex A72 1.7GHz Quad-Core CPU On-Chip Cache Memory L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB Clock Speed 1.7GHz Main Memory Interface 2.5GB LPDDR4 1.5GHz 64bit Graphics Graphic resolution : 1920x1080 Output resolution : 1920x1080 (Scale up from graphic processing result.) Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available) Multimedia *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG IO Ports USB 2.0 Operating System Tizen 4.0 (VDLinux) Certification Safety 60950-1 EMC Class B(TBD) Security 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP Accessory Included Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries Optional Stand STN-L3240E Mount WMN4070SE (Land Only) WMN750ME Specialty CML400XK Media Player Media Player N/A
