Power
Power Supply

AC 100 - 240 V, 50/60 Hz

Power Consumption (Sleep Mode)

less than 0.5W

Power Consumption (Max[W/h])

275

Power Consumption (Typical[W/h])

197

Features
Key

UHD Signage with Built-in MagicInfo Lite

Special H/W

Temperature Sensor, Built in Speaker

Special S/W

Auto Source Switching & Recovery, Button Lock, Hot key option, Plug&Play (Initial Setting)

Internal Player
Processor

Cortex A72 1.7GHz Quad-Core CPU

Operating System

Tizen 6.5

Storage (FDM)

8 GB (3 GB available)

Accessories
Included in Box

Quick Setup Guide,
Warranty Card,
Power Cord
RS232C(IN) Gender
Remote Controller & Batteries

Optional Stand

In Box

Optional Mount

WMN-8200SC

Mechanical Specs
VESA Mount

600 X 400

VESA Mount Screw (Min~Max)

M8, 16~18mm

Bezel Width (mm)

3 bezeless

Set Dimension (mm)

2180.6 x 1243.9 x 48.4

Package Dimension (mm)

2379 x 1431 x 350

Set Weight (kg)

56.3

Package Weight (kg)

87.8

Design
Bezel Color

Titan Black

Certification
Safety

60950-1 / 62368-1

EMC

Class B

Display Panel
Measured

97.5

Resolution

3840x2160(16:9)

Brightness(Typ.)

450 nit

Orientation

Landscape

Haze

2%

Contrast Ratio (Typ.)

5000:1

Active Display Area

2158.85 (H) x 1214.35 (V)

Pixel Pitch (mm)

0.5622 x 0.5622

Color Gamut

DCI 93%

Operation Hour

16/7

Class

98

Connectivity/Sound
VIDEO Input

HDMI 2.0 (4)

USB Input

USB 2.0 x 2

WiFi / BT

O / O

External Control

RS232C(in), RJ45(in)

Speaker

40W 2.2ch

Operating Condition
Relative Humidity

10~80%

Temperature

0?~ 40?
