Panel QBR24R-ODX Diagonal Size 24 Type ADS Resolution 1920*1080 (Full HD) Pixel Pitch(mm) 0.2745 x 0.2745 Active Display Area(mm) 527.04 (H) x 296.46 (V) Brightness(Typ.) 250 nit Contrast Ratio 1000:1 Viewing Angle(H/V) 178/178 Response Time(G-to-G) 14ms(Typ.) Display Colors 16.7 M (real 6bit, dither 8bit) Color Gamut 72% Operation Hour 16/7 Haze 25% Display Dynamic C/R MEGA H-Scanning Frequency 56 ~ 84.5kHz V-Scanning Frequency 48 ~ 75HZ Maximum Pixel Frequency 594MHz Sound Speaker Type Built in Speaker(5W) Connectivity Input RGB - Video HDMI 1.4 (1) HDCP HDCP 2.2 USB USB 2.0 x 1 Output Audio Stereo Mini Jack External Control RS232C(in) thru stereo jack, RJ45 Power Type Internal Power Supply AC 100 - 240 V, 50/60 Hz Power Consumption Max[W/h] 38.5 Typical[W/h] 25.0 Rating[W/h] 35.0 BTU(Max) 131.3 Sleep mode 0.5 Mechanical Specification Dimension (mm) Set 547.9 x 334.4 x 31.8 Package 620 x 419 x 122 Weight (kg) Set 3.0 Package 4.1 VESA Mount (mm) 100 X 100 Bezel Width (mm) 17.9mm(U/B), 9.4mm(L/R) Feature Key Features Small Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0 Orientation N/A Remote Control N/A Special Features H/W : Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(5W 1ch), IP5x Rating, Wi-Fi/BT S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting) Internal Player Processor Cortex A72 1.7GHz Quad-Core CPU On-Chip Cache Memory L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB Clock Speed 1.7GHz Main Memory Interface 2.5GB LPDDR4 1.5GHz 64bit Graphics Graphic resolution : 1920x1080 Output resolution : 1920x1080 (Scale up from graphic processing result.) Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available) Multimedia *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG IO Ports USB 2.0 Operating System Tizen 4.0 (VDLinux) Certification Safety 60950-1 EMC Class B Security 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP Accessory Included Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries Optional Stand - Mount - Specialty - Media Player Media Player N/A
