TS-h1886XU-RP-D1622-32G CPU Intel® Xeon® D-1622 4-core 2.60 GHz processor, up to 3.2 GHz CPU Architecture 64-bit x86 Floating Point Unit Encryption Engine (AES-NI) System Memory 32 GB UDIMM DDR4 ECC (2 x 16GB) Maximum Memory 128 GB (4 x 32 GB) Memory Slot 4 x UDIMM DDR4 Flash Memory 5GB (Dual boot OS protection) Drive Bay Front: 12 x 3.5-inch SATA 6Gb/s, 3Gb/s Rear: 6 x 2.5-inch SATA 6Gb/s, 3Gb/s Drive Compatibility 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives Hot-swappable SSD Cache Acceleration Support SR-IOV Gigabit Ethernet Port (RJ45) 4 10 Gigabit Ethernet Port 2 x 10GbE SFP+ SmartNIC port Pre-installed with a 10GbE PCIe adapter Wake on LAN (WOL) Jumbo Frame PCIe Slot 4 Slot 1: PCIe Gen 3 x4 Slot 2: PCIe Gen 3 x8 or x4 Slot 3: PCIe Gen 3 x4 Slot 4: PCIe Gen 3 x8 or x4 *Slot 4 is preinstalled with a 10GbE network adapter. **Slot 2 provides the width of PCIe Gen 3 x8 when Slot 1 is not in use, and provides the width of PCIe Gen 3 x4 when Slot 1 is in use. ***Slot 4 provides the width of PCIe Gen 3 x8 when Slot 3 is not in use, and provides the width of PCIe Gen 3 x4 when Slot 3 is in use. USB 3.2 Gen 1 port 2 Form Factor Rackmount LED Indicators HDD, SSD, Status, LAN, storage expansion port status Buttons Power, Reset Dimensions (HxWxD) 88.3 × 482 × 549.7 mm Weight (Net) 12.73 kg Weight (Gross) 18.69 kg Operating temperature 0 - 40 °C (32°F - 104°F) Storage Temperature -20 - 70°C (-4°F - 158°F) Relative Humidity 5-95% RH non-condensing, wet bulb: 27°C (80.6°F) Power Supply Unit 550W(x2), 100-240V Power Consumption: Operating Mode, Typical 117.92 W Tested with drives fully populated. Fan System fan: 3 x 60mm, 12VDC System Warning Buzzer Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
