CUDA Cores 896 GPU Memory 8 GB GDDR6 Peak FP32 Performance 2.50 TFLOPS Memory Interface 128-bit Memory Bandwidth 160 GB/s Max Power Consumption 50 W System Interface PCI Express 3.0 x16 Display Connectors 4x mDP Max Digital Resolution 7680 x 4320 at 60 Hz Max Displays 4x at 5K | 5120 x 2880 at 60 Hz HDR Support Yes Quad Buffered Stereo Yes NVENC | NVDEC 2x H.264 and HVEC Encoders 1x Decode Engine Form Factor Low-Profile Single Slot Thermal Solution Active Fansink 3D GRAPHICS ARCHITECTURE Scalable geometry architecture Hardware tessellation engine NVIDIA GigaThread engine with 3 async copy engines Shader Model 5.1 (OpenGL 4.5 and DirectX 12) Up to 32K x 32K texture and render processing Transparent multisampling and super sampling 16x angle independent anisotropic filtering 32-bit per-component floating point texture filtering and blending 64x full scene antialiasing (FSAA) Decode acceleration for MPEG-2, MPEG-4 Part 2 Advanced Simple Profile, H.264, HEVC, MVC, VC1, DivX (version 3.11 and later), and Flash (10.1 and later) Dedicated H.264 and HEVC Encoder Blu-ray dual-stream hardware acceleration (supporting HD picture-in-picture playback) NVIDIA GPU Boost (automatically improves GPU engine throughput to maximize application performance) NVIDIA CUDA PARALLEL PROCESSING ARCHITECTURE SMM architecture (NVIDIA Turing streaming multi-processor design that delivers greater processing and efficiency) Dynamic Parallelism (GPU dynamically spawns new threads without going back to the CPU) API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran 96 KB of RAM (dedicated shared memory per SM) Advanced Display Features Support for any combination of four connected displays Four DisplayPort 1.4 outputs (supporting resolutions such as 3840 x 2160 at 120 Hz and 5120 x 2880 at 60 Hz) HDR support over DisplayPort 1.4 (SMPTE 2084/2086, BT. 2020) (4K at 60 Hz 10b/12b HEVC Decode, 4K at 60 Hz 10b HEVC Encode) HDCP 2.2 support over DisplayPort, DVI, and HDMI adapters 12-bit internal display pipeline (hardware support for 12-bit scanout on supported panels, applications, and connection) Full OpenGL quad buffered stereo support Underscan/overscan compensation and hardware scaling NVIDIA RTX Desktop Manager Support for Nvidia Mosaic DisplayPort and HDMI Digital Audio Support for the following audio modes: Dolby Digital (AC3), DTS 5.1, Multi-channel (7.1) LPCM, Dolby Digital Plus (DD+), and MPEG-2/MPEG-4 AAC Data rates of 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176 KHz, and 192 KHz Word sizes of 16-bit, 20-bit, and 24-bit The mini-DisplayPort connectors are designed with a custom retention mechanism to firmly secure its connection with the display cable. SUPPORTED PLATFORMS Microsoft Windows 10 (64-bit) Red Hat Enterprise Linux 7.x SUSE Linux Enterprise Desktop 15.x OpenSuse 15 Fedora 31 Ubuntu 18.04 FreeBSD 11.x Solaris 11 Minimum System Requirements Intel Core i5, i7, i9, or Xeon processor or later AMD Ryzen or Epyc class processor or later PCI Express 4.0 x16 (preferred) expansion slot System memory greater than or equal to GPU memory, twice the GPU memory recommendedInternet connection for driver installation DisplayPort 1.4a (preferred), HDMI, or DVI compatible display(s) PACKAGE CONTAINS NVIDIA T1000 8 GB professional graphics card Unattached low-profile (SFF) bracket Attached full-height (ATX) bracket NVIDIA Turing Quick Start Guide NVIDIA Turing Support Guide 4x mDP to DisplayPort adapters
