Picture/Display • LCD panel type: IPS technology • Backlight type: W-LED system • Panel Size: 23.8 inch/60.5 cm • Display Screen Coating: Anti-Glare, 3H, Haze 25% • Effective viewing area: 527 (H) x 296.5 (V) • Aspect ratio: 16:9 • Optimum resolution: 1920 x 1080 @ 60 Hz • Pixel Density: 93 PPI • Response time (typical): 5 ms (Grey to Grey)* • Brightness: 250 cd/m˛ • Contrast ratio (typical): 1000:1 • SmartContrast: 50,000,000:1 • Pixel pitch: 0.275 x 0.275 mm • Viewing angle: 178ş (H)/178ş (V), @ C/R > 10 • Flicker-free • Picture enhancement: SmartImage • Colour gamut (typical): NTSC 72% (CIE 1931) • Display colours: 16.7 M • Scanning Frequency: 30–85 kHz (H) / 48–75 Hz (V) • sRGB • EasyRead • LowBlue Mode Touch • Touch technology: Projected capacitive • Touch points: 10 points • Touch method: Stylus, finger • Touch interface: USB • Touch glass hardness: 7 H • Touch active area: 528 mm (H) x 297.5 mm (V) • Operating system: Windows 10/8.1/8/7; Android 7.1/7.0/6.0/5.0/4.4* • Ingress protection: IP54 - front only • Sealability: Touchscreen sealed to bezel; Touchscreen sealed to LCD Connectivity • Signal Input: VGA (Analogue), DVI-D (digital, HDCP), DisplayPort 1.2, HDMI 1.4 • USB: USB 3.1 x 2 (1 w/fast charging)* • Sync Input: Separate Sync, Sync on Green • Audio (In/Out): PC audio-in, Headphone out Convenience • Built-in Speakers: 2 W x 2 • User convenience: SmartImage, Input, Brightness, Menu, Power On/Off • Control software: SmartControl • OSD Languages: Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian • Other convenience: Kensington lock, VESA mount (100 x 100 mm) • Plug and Play Compatibility: DDC/CI, sRGB, Windows 10 / 8.1 / 8 / 7 Stand • Tilt: -5–90 degree • Folding angle: 0–70 degrees Power • ECO mode: 11.5 W (typ.) • On mode: 16 W (typ.) (EnergyStar 7.0 test method) • Standby mode: < 0.5 W (typ.) • Off mode: < 0.3 W (typ.) • Energy Label Class: A • Power LED indicator: Operation - White, Standby mode - White (flashing) • Power supply: External, 100-240 VAC, 50-60 Hz Dimensions • Product with stand (max height): 554 x 413 x 227 mm • Product without stand (mm): 554 x 338 x 50 mm • Packaging in mm (W x H x D): 620 x 433 x 168 mm Weight • Product with stand (kg): 8.15 kg • Product without stand (kg): 4.86 kg • Product with packaging (kg): 11.06 kg Operating conditions • Temperature range (operation): 0°C to 40°C °C • Temperature range (storage): -20°C to 60°C °C • Relative humidity: 20%–80% % • Altitude: Operation: +12,000 ft (3658 m), Nonoperation: +40,000 ft (12,192 m) • MTBF (demonstrated): 70,000 hrs (excluded backlight) Sustainability • Environmental and energy: EnergyStar 7.0, EPEAT*, TCO edge, RoHS, WEEE • Recyclable packaging material: 100 % • Specific Substances: PVC/BFR free housing, Mercury free, Lead free Compliance and standards • Regulatory Approvals: CE Mark, FCC Class B, SEMKO, EPA, UKRAINIAN, ICES-003, TUV/GS, TUV Ergo, CU-EAC Cabinet • Front bezel: Black • Rear cover: Black • Foot: Black • Finish: Texture What's in the box? • Monitor with stand • Cables: D-Sub cable, HDMI cable, DP cable, USB-A to B cable, Audio cable, Power cable • User Documentation • Accessory: Stylus touch pen x 1 (black)
