20 U.2 NVMe storage slots – Ultra-fast, high-density storage for demanding workloads.
100G high-speed networking – 2× 100G QSFP28 ports, 4× 25G SFP28 ports, 4× 10G SFP+ ports, 2× 10G Ethernet ports, and an extra SFF-8644 interface for flexible connectivity.
16-core 2 GHz ARM CPU + 32GB DDR4 RAM – High-performance processing for networking, storage, and virtualization.
Massive energy savings – Cut power consumption and heat output while maintaining high performance – an eco-friendly solution for data-heavy environments.
Runs RouterOS – The most flexible, modular networking OS. Supports advanced storage capabilities, including exporting block devices over NVMe-TCP, encryption layers, and modular storage configurations for scalable infrastructure. No subscriptions. No paywalls.
Container-ready – Run MinIO, Nextcloud, Shinobi, Frigate, and other OCI compliant containers with ease. We’ve added two USB ports for additional devices and further adaptability.
Includes dual hot-swappable power supplies – Ensuring uninterrupted operation and quick replacement without unnecessary downtime.

Specifications
Details
Product code RDS2216-2XG-4S+4XS-2XQ
Architecture ARM 64bit
CPU AL73400
CPU core count 16
CPU nominal frequency 2000 MHz
Switch chip model 98DX4310
RouterOS license 6
Operating System RouterOS v7 (Special ROSE edition)
Size of RAM 32 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -20°C to 50°C
IPsec hardware acceleration Yes

Powering
Details
Number of AC inputs 2
AC input range 100-240
Frequency (Hz) 50-60
Max power consumption 286 W
Max power consumption without attachments 105 W
Cooling type 10 fans

Ethernet
Details
10/100/1000 Ethernet ports 1
Number of 1G/2.5G/5G/10G Ethernet ports 2

Fiber
Details
SFP+ ports 4
Number of 25G SFP28 ports 4
Number of 100G QSFP28 ports 2

Peripherals
Details
Serial console port RJ45
Number of USB ports 2
USB Power Reset Yes
USB slot type USB 3.0 type A
Max USB current (A) 1
Number of M.2 slots 2

Other
Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Mode button Yes

Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
