Specifications
Details
Product code CSS610-1Gi-7R-2S+OUT
Switch chip model 88E6193X
Dimensions 304 x 212 x 71 mm
Operating System SwitchOS Lite
Storage size 64 KB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C

Powering
Details
Number of DC inputs 3 (DC jack, 2-pin terminal, PoE-IN)
DC jack input Voltage 12-57 V
2-pin terminal input Voltage 12-57 V
Max power consumption 29 W
Max power consumption without attachments 7 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 12-57 V

PoE-out
Details
PoE-out ports Ether8
PoE out Passive PoE
Max out per port output (input 18-30 V) 600 mA
Max out per port output (input 30-57 V) 450 mA
Max total out (A) 600 mA

Ethernet
Details
10/100/1000 Ethernet ports 8
Number of 1G Ethernet ports with Reverse PoE (PoE-in) 7
Number of 1G Ethernet ports with PoE-out 1

Fiber
Details
SFP+ ports 2

Certification & Approvals
Details
Certification CE, EAC, ROHS
IP IP54
