Charakteristika produktu
Linka - Interaktívna
Čistý sínusový výstup
Účiník: 0,8
8 x 10A IEC

Výhody produktu
Výhody
USB & RS232 port & SNMP & EPO & ROO & 2 DRY KONTAKT

Technical characteristics
Input voltage 175 - 288 V
Primary frequency 47-63 Hz
Number of phases primary 1
Output voltage 208-240 V
Secondary frequency 50-60 Hz
Output effective power 1600 W
Output apparent power 2000 VA
USB interface Yes
With communication interface RS-232 No
SNMP Yes
Voltage type AC
Height 238 mm
Width 170 mm
Depth 438 mm
Weight 23 kg
Bridging time full load 0.00016 min
Suitable for network-management Yes
USV- technology Line-interactive
Construction type Free standing model
Max. voltage distortion output (linear load) 3 %
Output power factor 0.8
Overall efficiency 85 %
Efficiency in eco-mode 98 %
Potential free switch contact Yes
Auto shut down function Yes
Input connection C20
Number of output connections C13 8
Number of output connections C19 0
Number of output connections with protective contact CEE 7/3 (type F) 0
Number of output connections fixed connection 0
Degree of protection (IP) IP20
Operating / setting temperature 0-40 °C
Storage temperature 0-50 °C
Supply current 7-11 A
Sound level 45 dB
Terminal marking indication Yes
Type of load Not applicable
With socket outlet Yes
Contains Batteries and/or Accumulator Yes
