First supported version V200R024C00
Installation Type Junction Box
Dimensions without packaging (H x W x D) [mm(in.)] 86 mm x 86 mm x 42.5 mm (3.39 in. x 3.39 in. x 1.67 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 98 mm x 117 mm x 73 mm (3.86 in. x 4.61 in. x 2.87 in.)
Weight without packaging [kg(lb)] 0.14 kg (0.31 lb)
Weight with packaging [kg(lb)] 0.24 kg (0.53 lb)
CPU 2-core, 1.2 GHz
Memory DDR3: 256 MB
Power supply mode PoE
Storage NAND Flash 256 MB
Input voltage range [V] PoE: 802.3af
Service port surge protection PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C
Maximum number of physical ports on the entire device GE (RJ45) x 2, 10M/100M/1000M auto-sensing
Long-term operating temperature [°C(°F)] 0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] –60 m to +5000 m (–196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa] 53kPa - 106kPa ETSI 300 019-2-3
Ground floating ground
Radio number 2
MIMO spatial streams Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2
Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax 5 GHz: 802.11a/n/ac/ac Wave 2/ax
Radio interface Built-in smart antennas
Antenna gain 2.4 GHz: 3 dBi/chain (peak value) 3 dBi (combined gain) 5 GHz: 2 dBi/chain (peak value) 1 dBi (combined gain)
Maximum transmit power 2.4 GHz: 17 dBm/chain 20 dBm (combined power) 5 GHz: 17 dBm/chain 20 dBm (combined power)
MTBF [year] 446
MTTR [hour] 2
Maximum power consumption [W] 9.1
Maximum heat dissipation [BTU/hour] 29.5
802.3bt power supply description The negotiated power supply mode is 802.3af, and no function is restricted.
802.3at power supply description The negotiated power supply mode is 802.3af, and no function is restricted.
802.3af power supply description The negotiated power supply mode is 802.3af, and no function is restricted.
Operating frequency band 2.4GHz,5GHz
Frequency stability [ppm] +/-20
