First supported version V200R024C00
Installation Type Desk,Wall,Ceiling,Junction Box
Dimensions without packaging (H x W x D) [mm(in.)] 160 mm x 86 mm x 38 mm (6.30 in. x 3.39 in. x 1.50 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 187 mm x 108 mm x 68 mm (7.36 in. x 4.25 in. x 2.68 in.)
Weight without packaging [kg(lb)] 0.23 kg (0.51 lb)
Weight with packaging [kg(lb)] 0.42 kg (0.93 lb)
CPU 2-core, 1.2 GHz
Memory DDR3: 256 MB
Console port None
Power supply mode PoE
Storage NAND Flash 256 MB
Rated input voltage [V] NA
Input voltage range [V] PoE: 802.3af
Service port surge protection PoE ports: Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion B Non-PoE ports: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms, criterion B
Maximum number of physical ports on the entire device GE (RJ45) x 5, 10M/100M/1000M auto-sensing
Long-term operating temperature [°C(°F)] 0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] –60 m to +5000 m (–196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa] 53kPa - 106kPa ETSI 300 019-2-3
Ground floating ground
Radio number 2
MIMO spatial streams Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2
Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax 5 GHz: 802.11a/n/ac/ac Wave 2/ax
Radio interface Built-in smart antennas
Antenna gain 2.4G: 4 dBi/chain (peak value) 2 dBi (combined gain) 5G: 4 dBi/chain (peak value) 1 dBi (combined gain)
Maximum transmit power 2.4G: 20 dBm/chain 23 dBm (combined power) 5G: 20 dBm/chain 23 dBm (combined power)
MTBF [year] 289.18
MTTR [hour] 2
Maximum power consumption [W] 9.4
Maximum heat dissipation [BTU/hour] 32.07
802.3bt power supply description The negotiated power supply mode is 802.3af, and no function is restricted.
802.3at power supply description The negotiated power supply mode is 802.3af, and no function is restricted.
802.3af power supply description The negotiated power supply mode is 802.3af, and no function is restricted.
Operating frequency band 2.4GHz,5GHz
Frequency stability [ppm] +/-20
