Dimensions without packaging (H x W x D) Basic dimensions (excluding the parts protruding from the body): 35 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 36.5 mm x 210.0 mm x 131.7 mm (1.44 in. x 8.27 in. x 5.19 in.)
Chassis height 0.8
Installation type Desk mounting,Wall mounting
Weight without packaging 1.11 (2.45)
Typical power consumption 11
Static power consumption 4
100% power consumption 11
Maximum number of physical ports on the entire device 10
Long-term operating temperature 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.)
Restriction on the operating temperature variation rate When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage temperature –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity 5% RH to 95% RH (non-condensing)
Long-term operating altitude 0–5000 m (0–16404 ft.)
Storage altitude 0-5000 m (0-16404 ft.)
Power supply mode Power adapter
Rated input voltage Power adapter input: 100–240 V AC; 50/60 Hz Power adapter output: 56 V DC
Input voltage range Power adapter input: 90 V AC to 264 V AC; 47 Hz to 63 Hz
Service port surge protection Common mode: ±4 kV
Power supply surge protection Differential mode: ±6 kV; common mode: ±6 kV
