Installation Type Rack,Desk,Wall
Dimensions without packaging (H x W x D) [mm(in.)] Basic: 43.6 mm x 250 mm x 210 mm (1.72 in. x 9.84 in. x 8.27 in.) Maximum: 43.6 mm x 250 mm x 215 mm (1.72 in. x 9.84 in. x 8.46 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 110 mm x 465 mm x 335 mm (4.33 in. x 18.31 in. x 13.19 in.)
Weight without packaging [kg(lb)] 1.9kg
Weight with packaging [kg(lb)] 2.55 kg (5.62 lb)
Console port RJ45
Power supply mode DC power adapter
Service port surge protection 6 kV in common mode
Maximum number of physical ports on the entire device 2 x 10GE (SFP+) + 10 x GE (RJ45)
Long-term operating temperature [°C(°F)] 0°C to 45°C (32°F to 113°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] –60 m to +5000 m (–196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa] 53kPa - 106kPa ETSI 300 019-2-3
Ground Ground
USB 1 x USB 2.0 (host type A) port
Maximum power consumption [W] 23.58
Maximum heat dissipation [BTU/hour] 80.45
