Specifications Processor / System Bus 1 x Socket P (LGA 3647) Intel® Xeon® W-3200 Processors Core Logic Intel® C621 Chipset Memory Total Slots : 12 (6-channel per CPU, 12 DIMM per CPU) Capacity : Maximum up to 1536GB RDIMM Memory Type : DDR4 2933/2666 Memory Size : 128GB, 64GB, 32GB, 16GB RDIMM/LRDIMM Expansion Slots Total 5 slots Location-1: PCIe x16 slot (Gen3 x16 link, FH, FL), will be occupied when NVMe riser card is installed. Location-3: PCIe x16 slot (Gen3 x16 link, FH, FL) Location-4: PCIe x16 slot (Gen3 x4 link, FH, FL) Location-5: PCIe x16 slot (Gen3 x16 link, FH, FL) Location-7: PCIe x16 slot (Gen3 x16 link, FH, FL) Storage SATA Controller : Intel® C621 8 x SATA3 6Gb/s ports + 1 x M.2 connector (SATA 6Gb/s & PCIe® Gen3 x4 link) Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only) (Support Software RAID ) SATA Controller : ASMedia® SATA 6Gb/s controller 2 x SATA3 6Gb/s ports Drive Bays 8 x Internal 3.5" or 2.5" Tooless Storage Bays (Backplane supports 4 x SATA/SAS + 4 x SATA/SAS/NVME devices) 1 x M.2 Socket 3, up to 22110 type (SATA mode & PCIe Gen3 x4 link) Optional Kit: ASUS NVMe riser/PIKE card is needed for NVMe/SAS devices. Auxiliary Storage FDD/CD/DVD 2 x 5.25" media bays (Optional DVD-ROM/DVD-RW) Networking 1 x Dual Port Intel X550-AT2 10GbE LAN controller Front I/O Ports 4 x USB 3.2 Gen1 ports 1 x Headphone jack 1 x Microphone jack Rear I/O Ports 2 x USB 3.2 Gen2 ports (1 x Type-A, 1 x Type-C) 4 x USB 3.2 Gen1 ports 2 x 10GbE LAN ports (RJ45) 5 x Audio jacks (7.1-channel HD Audio) 1 x Optical S/PDIF output 1 x COM port (optional) 1 x VGA port (optional, from BMC) Switch/LED Front: 1 x Power Switch/LED 1 x Reset Switch 1 x HDD Access LED Rear: 1 x BIOS Flash-back Button OS Support Please find the latest OS support from https://www.asus.com/event/Server/OS_support_list/OS.html Management Solution ASUS Control Center Enterprise (Optional) ASMB9-iKVM (on-board) Regulatory Compliance BSMI, CE, FCC(Class A) Dimensions 532mm x 243mm x 582mm 21.0” x 9.5” x 22.9” Weight Net Weight: 18.0 kg Gross Weight: 22.5 kg Power Supply 2000W Platinum ATX Power Supply (100-240Vac, 15-12A, 60/50Hz) 750W Gold ATX Power Supply (100-240Vac, 9-4.5A, 60/50Hz) Environment Operation temperature: 10? ~ 35? Non operation temperature: -40? ~ 70? Non operation humidity: 20% ~ 90% ( Non condensing) Note * M.2 socket (PCIe mode) shares the bandwidth with Location-4 PCIe x16 slot (Gen3 x4 link). ** An external fan module is required with NVIDIA Tesla cards, and acoustic level will be high. *** Suggest to use Intel Xeon W-3200 processors which support PCIe slots with full CPU links(64 lanes). Intel Xeon Scalable processors are supported, but there may be some limitations of CPU links(48 lanes).
